Customizable O-Type Extrusion Machine 2LPE / 3LPE / FBE Coating Line
Product Description
A complete set of O-type Extrusion Anti-Corrosion 3LPE 2LPE FBE Coating Machine includes systems of steel pipe transmission, shot blasting, dust collector, pipe heating, electrostatic spraying powder, PE and adhesive coating, water cooling, edge cutting, hydraulic and pneumatic device, detecting and electric controlling system.
With exceptional resistance to chemical degradation, the 3LPE-coated O-extruded steel pipe demonstrates remarkable stability against corrosive agents like acids, bases, salt solutions, and oxidizers. This protective coating technology enables safe material transportation in challenging environments while prolonging pipeline service life. Its applications span across key industries including hydrocarbon transmission, municipal water management, and industrial fluid transportation systems.
Technological processes
Upload pipes→pipes screw conveyor→rust removal→intermediate frequency heating→Epoxy powder coating→outer layer adhesive polyethylene coating→cooling spray→pipes screw conveyor→grinding pipe ends→unload pipes
Product Parameters
(1) Steel pipe range:50mm-426mm
(2) Processing capacity:≥150m2/h
(3) Cleaning level:Sa2.5
(4) Materials for production: Epoxy powder, adhesive, polyethylene
Our Advantages
- Cutting-edge technology: Innovative processes enhance efficiency
- All-weather stable operation: Failure rate <0.5%
- Automated production lines: Labor costs have dropped by over 40%
- International Anti-corrosion Certification (ISO/CE)
- Full-process service: design → installation → commissioning → training
- Technical support for the expert workstation of high-end plastic machinery and equipment
Detailed Photos
Customer cases
Company Profile
Qingdao Huashida Machinery Co., LTD, is a manufacturer of series of plastic pipe machines, municipal pipe machines, pipe insulation&anticorrosion machines, and pipe jointing&anticorrosion materials, with 21 years of production experience.
Our main products are:
1. HDPE jacket pipe for pre-insulated pipe Production Line (110-2000mm)
2. Rigid pre-insulated pipe Production Line
3. Flexible pre-insulated pipe(PERT) production line
4. Steel pipe FBE/2LPE/3LPE anti-corrosion coating line
5. Steel pipe derusting line
6. PE pressure pipe/Water Gas supply pipe production line
6. PP/PE plastic board/sheet/geomembrane production line
7. NBR PVC Thermal insulation tube/plate production line
8.Pipeline anti-corrosion materials and instruments: heat shrink joint coating sleeve, electro-fusion weldable joint sleeve, portable welding gun(extruder), PE PP welding rod.
We have been working with more than 400 overseas customers and exporting our products to Kazakhstan, Uzbekistan, Iran, Turkey, Russia, Nigeria and other countries.
Factory overview
Delivery
